Spain warehouse! Rooftop 400w S3 wind power generator with controller Spain warehouse! Rooftop 400w S3 wind power generator with controller
Spain warehouse! Rooftop 400w S3 wind power generator with controller The items inside the package 1 wind generator host 3/5...
Spain warehouse! Rooftop 400w S3 wind power generator with controller
The items inside the package
1 wind generator host
3/5 blades
1 wind generator controller
1 hub+1 hood+1 flange+ screws
Installation tools
1 user manual
400W Horizontal Axis Wind Generator pictures:
3 blades and 5 blades for your option
3 Phase 12v/24v ac permanent magnet generator for this wind generator
12V/24V Controller pictures:
Convert AC to DC, charge to the battery
400W Horizontal Axis Wind Generator features:
1.Low start up speed, high wind energy utilization.
2.Easy installation, tube or flange connection optional.
3.Blades using new art of precision injection.
4.Body of casting aluminum alloy, with 2 bearings swivel.
5.Patented permanent magnet ac generator with special stator,effectively reduce torque.
6.CE, ISO,TUV certified.
400W Horizontal Axis Wind Generator technical data：
| Model |
NE-400S3 |
| Rated power |
400W |
| Maximum power |
480W |
| Rated voltage |
12V/24V |
| Start-up wind speed |
2.0m/s |
| Rated wind speed |
11.5m/s |
| Survival wind speed |
65m/s |
| Top net weight |
9kg |
| Wheel diameter |
1.3m |
| Number of blades |
3/5 |
| Blades material |
Nylon fiber |
| Generator type |
Three phase permanent magnet AC synchronous generator |
| Magnet material |
NdFeB |
| Generator case |
Casting aluminum alloy |
| Control system |
Electromagnet/wind wheel yaw |
| Speed regulation |
Automatically adjust windward direction |
| Working temperature |
-40degC - 80degC |
| Design life |
20 y |
400w S3 wind generator power-wind speed curve
400W Horizontal Axis Wind Generator application:
Installation manual
Package
factory:
Spain warehouse! Rooftop 400w S3 wind power generator with controller
The items inside the package
1 wind generator host
3/5 blades
1 wind generator controller
1 hub+1 hood+1 flange+ screws
Installation tools
1 user manual
400W Horizontal Axis Wind Generator pictures:
3 blades and 5 blades for your option
3 Phase 12v/24v ac permanent magnet generator for this wind generator
12V/24V Controller pictures:
Convert AC to DC, charge to the battery
400W Horizontal Axis Wind Generator features:
1.Low start up speed, high wind energy utilization.
2.Easy installation, tube or flange connection optional.
3.Blades using new art of precision injection.
4.Body of casting aluminum alloy, with 2 bearings swivel.
5.Patented permanent magnet ac generator with special stator,effectively reduce torque.
6.CE, ISO,TUV certified.
400W Horizontal Axis Wind Generator technical data：
| Model |
NE-400S3 |
| Rated power |
400W |
| Maximum power |
480W |
| Rated voltage |
12V/24V |
| Start-up wind speed |
2.0m/s |
| Rated wind speed |
11.5m/s |
| Survival wind speed |
65m/s |
| Top net weight |
9kg |
| Wheel diameter |
1.3m |
| Number of blades |
3/5 |
| Blades material |
Nylon fiber |
| Generator type |
Three phase permanent magnet AC synchronous generator |
| Magnet material |
NdFeB |
| Generator case |
Casting aluminum alloy |
| Control system |
Electromagnet/wind wheel yaw |
| Speed regulation |
Automatically adjust windward direction |
| Working temperature |
-40degC - 80degC |
| Design life |
20 y |
400w S3 wind generator power-wind speed curve
400W Horizontal Axis Wind Generator application:
Installation manual
Package
factory:
